Call for price
Horsepower: 700 – 1250
Displacement: 2.0L – 8.0L
Horsepower: 700 – 1250
Displacement: 2.0L – 8.0L
| Super Core Reference Data | Compressor | Turbine | ||||||
|---|---|---|---|---|---|---|---|---|
| Super Core PN | CHRA PN | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim |
| 800270-5001S | 451888-0045 | 80mm | 108mm | 55 | 0.69 | 87mm | 80mm | 85 |
| Notes: | Turbine Kit PN | A/R | Inlet | Outlet | Wastegate | Divided | Trim | |
| Super Core and Turbine Kit Sold Separately | 757707-0005 | 1.01 | T4 | V-Band | Free Float | Y | 85 | |
| 757707-0006 | 1.15 | T4 | V-Band | Free Float | Y | 85 | ||
| 757707-0007 | 1.28 | T4 | V-Band | Free Float | Y | 85 | ||
| 757707-0008 | 1.44 | T4 | V-Band | Free Float | Y | 85 | ||
